The ESI/RM2 is a 2-channel shock tube initiator designed to be mounted on and powered by an EOD robot.
The ESI/RM1 has all the same features and specifications as the ESI/RM2, except that it provides one initiator channel.
Specifications
Approvals Certified by USAF Nonnuclear Munitions Safety Board (NNMSB) for USAF EOD operational use. USAF log number: 04-2-8
U.S. Navy Certified to MIL-STD-461E.
Weight ESI/RM1: 1 lb
ESI/RM2: 1.1 lbs
Size 5.7" x 3.7" x 2.0"
Operating Temperature -40°C to +85°Cv
Power Requirements 18 - 30VDC, 300mA for 3 seconds
